Zoomlion  ZE275G Crawler Hydraulic Excavator

‌SEO-Optimized Description (Concise Version):‌

Premium ‌second-hand Zoomlion ZE275G Crawler Hydraulic Excavators‌ for sale! These ‌used hydraulic excavators‌ feature:

• ‌Powerful ISUZU/Caterpillar engines‌ (66–92 kW)
• ‌1.0–1.5m³ bucket capacity‌
• ‌30,900 kPa hydraulic systems‌
• ‌CE-certified with 6–12 months warranty‌

Ideal for ‌construction, mining, and marine projects‌. Fast global shipping (FOB/CFR terms). Contact for bulk orders!

The ZE275G is a heavy-duty platform developed by Zoomlion for large and medium-sized urban infrastructure and large-scale hydropower construction projects. It features a 33-ton capacity, equipped with a high-torque engine, large-displacement main pump, and high-bucket capacity. Utilizing a constant flow control system and technologies such as split power control and electro-hydraulic swing control, it effortlessly achieves high efficiency and productivity

High Power

1.Cummins B7 Engine

Customized Cummins B7 high-pressure common rail electronic fuel injection engine with National IV emission standards, rated power of 150kW, sufficient torque reserve, and strong performance. The customized universal characteristic curve ensures more complete combustion and lower fuel consumption.

2.Main Pump/Main Control Valve

Equipped with a new-generation positive displacement control main pump and main valve, featuring the largest displacement of 140cc among machines of the same tonnage class, the main valve offers lower pressure loss. Combined with technologies such as split-power control and boom electro-hydraulic control, it significantly enhances operational efficiency while improving controllability.

3.E-COT Control System

The independently developed positive flow control system optimizes the positive flow control program through four key technologies: load analysis, load matching, flow analysis, and torque matching. This significantly reduces hourly fuel consumption while ensuring smoother and more efficient operation.

Large Machine Body

1.All-new large-scale body styling

Adopting a new G series 33-ton large platform and exterior design, the vehicle features an enlarged body and a robust, rugged appearance. The panoramic cab and large fuel tank ensure high comfort and extended operation range

2.cockpit

Adopting a special-shaped pipe cross-section skeleton, improved sealing structure design, high-power air conditioning, and optimized layout of new air outlets. The safety, comfort, and reliability have been significantly improved..

3.Large section working device

The cross-sectional area of the boom increases by 10%, the cross-sectional area of the boom increases by 23%, and the hinge point of the pin shaft adopts a forged structure, greatly improving its service life.

4.High strength chassis

Adopting a 33 ton extended and widened platform, with a width increased to 2995mm, and equipped with anti-collision edge beams as standard; The chassis adopts double-sided support chain wheels, with 3 rail clamps standard on one side

Excellent Capability

1.Excellent handling of flat terrain and compound movements

Multi spool dynamic control technology: According to the needs of flat ground movement, the actual opening of each spool is dynamically controlled to achieve a higher level of flat ground composite movement performance, and the operation is simpler and smoother;

Dynamic matching technology for main pump flow: By combining working conditions and load changes, the main pump flow is dynamically adjusted to achieve a balance between maneuverability and fuel consumption, making it more user-friendly while reducing fuel consumption.

2.C-type soil hopper (standard)

The three major advantages of the professionally designed C-type earthmoving bucket are: standard 1.65 square bucket capacity, high operating efficiency; Not easy to stick to the bucket, higher loading efficiency; Professional reinforced design for greater durability.

3.D-type rock bucket (optional)

The three major advantages of the D-type rock bucket designed based on bionics are:

Optional 1.3-meter high-strength wear-resistant rock bucket can reduce the cutting resistance of the bucket teeth, making the operation faster and more stable, and the excavation more powerful;

4.Reduced the wear and impact of rocks on the bottom of the bucket, making the bucket more durable; The reduction of rock impact on the bottom of the bucket improves the stability of the entire machine and makes operation more comfortable.

2D/3D auxiliary construction guidance system (optional)

In construction projects that require high precision or invisible excavation such as slope trimming, trench excavation, river channel excavation, and riverbed leveling, a 2D/3D construction guidance system is used to complete construction operations according to guidance prompts, which increases efficiency by 40% compared to traditional construction

Intelligent Manufacturing

Global leading full process intelligent manufacturing factory

From a steel plate to an excavator, Zhonglian Smart Industry City Earthmoving Machinery Park has an industry-leading intelligent and flexible full process intelligent manufacturing excavator factory. With high-precision welding technology, highly reliable equipment technology, sedan level coating technology, and strict quality control, every delivered excavator has the ultimate quality and consistency.

High Return on Investment

10% increase in homework efficiency
