Zoomlion  ZE135G Crawler Hydraulic Excavator

‌High-Quality Used Crawler Hydraulic Excavators for Sale‌ – Discover premium ‌second-hand crawler hydraulic excavators‌ from trusted brands like ‌ZOOMLION‌, including the durable ‌ZE135G model‌. These ‌used hydraulic excavators‌ offer exceptional performance, fuel efficiency, and reliability for construction, mining, and earthmoving projects.✔ Rigorous quality inspections

✔ Competitive pricing on ‌used crawler excavators‌

✔ Fuel-efficient and low maintenance

✔ Reliable performance for demanding jobs

Contact us today to find the perfect ‌hydraulic excavator‌ for your project needs!

The ZE135G is a key model of 13-ton class earthwork excavator launched by Zoomlion, primarily used for basic earthwork operations such as excavation, loading, leveling, and trenching in road construction, municipal projects, and agricultural water conservancy. The machine features a new G-series exterior design, a customized national IV emission standard power system, and a mature load-adaptive control system, ensuring stable performance, reliability, fuel efficiency, and high productivity.

High Power

Cummins QSF4.5 engine

The newly customized high-power Cummins engine features ample torque reserve, low-speed operation, and unique fuel-saving electronic control characteristics, resulting in low fuel consumption. It adopts an EGR emission route and requires no urea addition.

Main pump

Equipped with a new high-displacement main pump for fast speed response

Main control valve

The main valve with a large bore is meticulously tuned, achieving a maximum working pressure of 37 MPa for enhanced performance. The optimized spool structure reduces pressure loss by over 20%, significantly minimizing energy consumption.

ELAC electronic control system

By employing technologies such as load control, PID control, load mutation technology, and heavy-load power enhancement, the product achieves reduced fuel consumption, improved operational coordination, and higher work efficiency.

High-capacity multi-stage filtration system

The system adopts a two-stage high-capacity filtration system, further improving filter element precision with a 99.9% impurity filtration rate. Additionally, a fuel cooler is utilized in the 13-ton model to precisely control fuel temperature, ensuring the engine remains in optimal condition. This not only extends the engine's lifespan but also reduces fuel consumption.

Large Machine Body

Brand new large-sized body design

The development of the new G series platform adopts the new family exterior design of the G series, which makes the appearance more atmospheric and the operation more stable; The interior cabin space of the vehicle has increased, and the sealing and air conditioning have been comprehensively upgraded, greatly improving the driving comfort experience; Further increase the fuel tank capacity to enhance the product's operational endurance.

cockpit

Adopting a special-shaped pipe cross-section skeleton, improved sealing structure design, high-power air conditioning, and optimized layout of new air outlets. The safety, comfort, and reliability have been significantly improved.

Excellent Capability

1.C-type soil hopper (standard)

The three major advantages of the professionally designed C-type earthmoving bucket are: standard 0.6 square bucket capacity, high operating efficiency; Not easy to stick to the bucket, higher loading efficiency; Professional reinforced design for greater durability.

2.The design of the boom section box increases the overall section by 9%, and the front, middle, and rear supports are designed with high-strength structures for higher strength and better adaptability to harsh working conditions;The front and rear supports of the boom adopt high-strength structures, with a 6% increase in overall cross-section, larger bearing area, and more reliable performance.

3.The frame adopts raised D-shaped side beams and raised I-shaped main beams, and key parts are made of high-strength steel plates. After rigorous durability tests, the overall strength is high and the safety is better.

4.Replacing the idler wheel with the idler wheel results in a higher safety factor and greater resistance to bending and twisting, avoiding damage to the drag chain wheel and providing more effective protection for the track.

Intelligent Manufacturing

Global leading full process intelligent manufacturing factory

From a steel plate to an excavator, Zhonglian Smart Industry City Earthmoving Machinery Park has an industry-leading intelligent and flexible full process intelligent manufacturing excavator factory. With high-precision welding technology, highly reliable equipment technology, sedan level coating technology, and strict quality control, every delivered excavator has the ultimate quality and consistency.

High Return on Investment

The comprehensive fuel consumption has been reduced by 4.2%, while the workload remains the same and fuel efficiency has been improved

5.1%
